Site ready, with one touch start, The 3000 is a portable hydronic surface heat system combined with multi-tasking proficiency. Thaw ground, heat, warm/cure during cold weather concrete pour or pre-pour warming. Use for ground frost prevention and other heat applications in extreme cold environments. Maintain reliable performance throughout projects with optional remote control technologies.

The Fusion 3000's built-in a spill containment system comes standard. Special safety sensors shut equipment off during a spill. Flex Guard is designed to hold 150% containment should an accident occur.

Planned, built, and designed for real time, cost savings. With far fewer maintenance and repair calls during winter construction, stay on schedule even at -30º below.

8,295 lbs. (3,174 kg) (with Genset, fully fueled)
178.5 in. (453 cm) 96 in. (244 cm)
91 in. (231 cm)
1075 lbs (488 kg) (with Genset)
170 Gallons (644 liters) #1 Diesel Fuel
1.75 GPH burner nozzle, without generator (at full operation)
One 280,000 Input BTU 50ºF – 190ºF
87% (with fuel pre-heater)
80 US gallons (303 liters)
3,000 ft. [4 x 750 ft.] x 5/8 in. ID, 914 m [4 x 69.49 m] x16 mm ID
One 3/4 hp
One
15 gal. (57 liters)
Direct drive, high/low speed, (forward & reverse) Freewheeling out and in reverse with soft start & stop
Up to 234,000 BTUs
Up to 6,000 sq. ft.(557 sq m)
Up to 18,000 sq. ft. (optimal conditions slab on grade)

Weight
Length
Width Height
Tongue Weight:
Fuel Capacity
Fuel Requirements: Fuel Consumption Boilers
Operating Temp
Boiler Efficiency
Heat Transfer Fluid
Heat Transfer Hose Circulation Pump
Fill Pump
Reserve Tank
Hose Reel Space Heating
Thaw Area
Cure Area

MAXCURE Maximize curing in the harshest cold weather concreting conditions Max Cure controls the supply or return temperature for balanced heating when curing. It is fuel efficient heat control for frost prevention, pre-pours, and Spoil pile warming.

Closed Loop System • Move heated fluid vertically or sideways • Use on columns, bridge decks and other applications • Uses no external reservoirs • Maximize heat and fuel efficiency Multi Zone Layout
Use one zone for smaller jobs. The use of multiple zones creates higher return temps for a quicker and more effective thaw. Zone heat control throughout the layout equalizes heat for more consistent concrete curing. Heavy Duty Hose Reel
Reel has: high/low speed, forward/reverse, and a direct drive gear box assembly for durability. An easy Soft start/stop control during hose layout and take-up makes for less wear and tear Freewheel option for faster setup. Auto-electric brake for transportation. Fuel Heater Adds 4% fuel savings with optimum fuel burn temp, assists boiler at high altitudes, prevents gelling in extreme cold weather.

FlexTemp Systems sets the bar by designing in digital technology for use in cold weather concreting warming/curing applications. The Fusion's (board controlled) heating can easily manage temperature distribution of complex structures, vertical columns and bridge decks.
